LAD-600 - MeanWell - DC UPS System - Battery Charger - 600W - 27.6V, 41.5V, 55.2V

€80.50 LAD-600B
€80.50 LAD-600C
€80.50 LAD-600D
€80.50 LAD-600BU
€80.50 LAD-600CU
€80.50 LAD-600DU

€80.50 Tax excluded

€80.50 Tax excluded

block Non disponibile - contattaci

We will send you an email once the product becomes available. your email address will not be shared with anyone else.

Quantity Unit price Total price Buy
1 €80.50 €80.50
5 €78.89 €394.45
10 €77.28 €772.80
20 €75.67 €1,513.40
Description

Available models: LAD-600B, LAD-600C, LAD-600D, LAD-600BU, LAD-600CU, LAD-600DU

Replaces the series Mean Well AD-55/155

  • Charger with UPS function
  • TTL Signals: AC OK, battery disconnected, reverse polarity, low battery, battery charging (blank version only)
  • UART communication (U version only)
  • Integrated buzzer alarm (U version only)
  • Integrated AC and battery ON/OFF switch to always ensure safety
  • Forced UPS mode for battery maintenance
  • Protections: short circuit / OLP / OVP / OTP / low battery voltage / reverse polarity
  • Working temperature -20°C - +60°C
  • Adjustable output voltage (-20%-+5%) through the CH1 - VR channel
  • Perfect for lead acid and lithium batteries
  • In accordance with GB17945/GB4717 (U version only)
  • Design 1U
  • 3 years warranty

Applications:

  • Fire emergencies and evacuations
  • Battery backup for safety
  • Security systems
  • Industrial automation

Our vote:

  • Reliability
  • Price
  • Features
    • [[voto1]There is no text provided to translate. Please provide the text you want translated.
    • [[voto2]There is no text provided to translate. Please provide the text you want translated.
    • [[voto3]There is no text provided to translate. Please provide the text you want translated.

Main technical specifications

MODEL LAD-360B/U LAD-360C/U LAD-360D /U
Exit number CH1 - CH2 CH1 - CH2 CH1 - CH2
Nominal Output Voltage 27.6V - 27.6V 41.5V -41.5V 55.2V - 55.2V
Rated current 18.74A - 1A 11.45AM - 1AM 7.87A - 1A
Power (Nominal) 600.02W 599.67W 600.02W
Efficiency 90% 91% 91%
Input voltage range 90 ~ 132VAC / 180 ~ 264VAC (via switch) - 240 ~ 370VDC
Working temperature -20 ~ +60 °C
Output connection Quickly
Dimensions 225*124*41mm
Certifications CB, EAC, CE, UKCA
For purchases and sampling CONTACT US



See also:

Data sheet
Mean Well
LAD-600B
New
7438645969377
3
Output Regulation Type
Constant Voltage / CV
Charger Type
DC UPS System Semplice
Output Voltage VDC
27.6
41
55.2
Input Voltage VAC
90~132VAC / 180~264VAC
90~132VAC / 180~264VAC
Operating Temperature
-4°F / +140°F
Rating
453
Power W
600
Net Weight
1 kg
Output Voltage Nr.
2
IP Protection Grade
IP20
Warranty
2 Years
Mechanical Mounting Format
Boxed - Frame Assembly
Efficiency
90%
91%
Dimensions
225x124x41mm
Output Current mA
7800
11400
18750
Input Connector
At Speed
Output Connection
At Speed
Certifications
EAC, CB, CE, UKCA
Special Features
Battery low protection / UPS Function
Applications
Fire & Gas Protection
Security
Product Family
LAD
