Relpower R12 Remote Control 2.4G CCT dimmer for 1 zone
zoom_out_map
chevron_left chevron_right

The product image may slightly differ as it is representative of the family and not the model.

NewNon disponibile - contattaci

Relpower R12 Remote Control 2.4G CCT dimmer for 1 zone

€18.20 Tax excluded

€18.20 Tax excluded

block Non disponibile - contattaci

We will send you an email once the product becomes available. your email address will not be shared with anyone else.

Quantity Unit price Total price Buy
1 €18.20 €18.20
5 €17.84 €89.18
10 €17.47 €174.72
20 €17.11 €342.16
Description

Ultra Thin RF Touch Remote - R12 for CCT Control

Main Features

  • Compatibility: Controls LED strips with adjustable color temperature (CCT, from warm white to cool white).
  • Intuitive Control: Ultra-sensitive touch slider for continuous color temperature adjustment.
  • Minimalist Design: Sleek, ultra-thin, available in white and black.
  • Long-lasting Battery: Powered by a CR2032 battery with up to 1 year of standby time.
  • Integrated Magnet: Can be attached to metal supports or the included base.
  • LED Indicator: Confirms operations with visual feedback.

Remote Control Features

  • On/Off Button:
    • Short press: turns the light on or off.
    • Long press (1-6s): adjusts brightness.
  • Touch Slider:
    • Adjusts color temperature (CCT) from warm white (WW 100%) to cool white (CW 100%).

Technical Specifications

  • Output Signal: RF (2.4 GHz).
  • Operating Voltage: 3VDC (CR2032 battery).
  • Power Consumption:
  • Operating Distance: 30 meters (unobstructed).
  • Battery Life: Up to 1 year in standby mode.

Certifications

  • EMC Standards: ETSI EN 301 489-1 V2.2.3, ETSI EN 301 489-17 V3.2.4.
  • Safety Standards: EN 61347-1:2015+A1:2021, EN 61347-2-13:2014+A1:2017.
  • Certifications: CE, EMC, RED.

Operating Conditions

  • Operating Temperature: From -30°C to +55°C.
  • Warranty: 5 years.

Dimensions and Weight

  • Dimensions: 156 x 48 x 22 mm.
  • Weight: 0.075 kg.
Data sheet
REL Power
R12
New
Led Dimming (interface)
RF remote control
Operating Temperature
-35°C / +55°C
